vacuum lines for BOV and wastegate...
can someone help me out here? i need to know where the vacuum lines run from the Blowoff valve and wastegate. if you can help that would be awesome. and also i have a question regarding the boost gauge and boost controller. how do you hook up the boost gauge and boost controller? im lost.. thanks guys
Australian_Booster is offline   Reply With Quote
Sponsored Links
Advertisement

Old 10-24-2009, 02:02 PM   #2
spoolie
International Administrator
No Tennspeed, No Life

spoolie's Avatar

Join Date: Dec 1969
Location: Brno, Czech Republic
Posts: 9,621
spoolie is just really nicespoolie is just really nicespoolie is just really nicespoolie is just really nice
Send a message via AIM to spoolie Send a message via MSN to spoolie Send a message via Yahoo to spoolie
The answers to all of your upcoming questions....all of them...I have them new for 30.00

__________________
spoolie is offline   Reply With Quote
Old 10-24-2009, 02:35 PM   #3
timmy tegra
Senior Member

timmy tegra's Avatar

Join Date: Mar 2008
Location: La vergne
Posts: 1,775
timmy tegra is an unknown quantity at this point
http://www.tmaturbo.com/install/diagram.jpg

http://www.dsmtuners.com/forums/atta...bov-hookup.jpg

Its not the greatest diagrams or such but it might help you.

And pick up spoolies books thats a great deal for both of those and they will help you out most defiantly.

Last edited by timmy tegra; 10-24-2009 at 02:37 PM..
timmy tegra is offline   Reply With Quote

Old 10-24-2009, 03:26 PM   #4
Australian_Booster
Junior Member

Join Date: Sep 2009
Posts: 61
Australian_Booster is on a distinguished road
thanks guys for the responses. ill check into those books spoolie. and nice diagrams. hahah helps though
Australian_Booster is offline   Reply With Quote
Old 10-24-2009, 05:25 PM   #5
drew89
Member

Join Date: Jun 2009
Posts: 151
drew89 is on a distinguished road
Look up some DIY vids on youtube, I have done that and it's worked for me.
drew89 is offline   Reply With Quote
Old 10-24-2009, 10:11 PM   #6
Australian_Booster
Junior Member

Join Date: Sep 2009
Posts: 61
Australian_Booster is on a distinguished road
okay cool. hey can any of yall tell me where the lines go that run to the bov and wastegate? every picture i look at doesnt show the actual lines, so i dont know how to run them.
Australian_Booster is offline   Reply With Quote
Old 10-24-2009, 11:59 PM   #7
Jankenshank
roflcpter.
Veteran Member

Jankenshank's Avatar

Join Date: Jul 2008
Location: Hendersonville. TN
Posts: 2,527
Jankenshank is on a distinguished road
Send a message via MSN to Jankenshank
Quote:
Originally Posted by Australian_Booster View Post
okay cool. hey can any of yall tell me where the lines go that run to the bov and wastegate? every picture i look at doesnt show the actual lines, so i dont know how to run them.
they run to the BOV and Wastegate.

also great fail at life....
Jankenshank is offline   Reply With Quote
Old 10-25-2009, 03:51 AM   #8
280zx!!!
Member

280zx!!!'s Avatar

Join Date: Jun 2008
Posts: 698
280zx!!! is on a distinguished road
the lines to the bov and wastegate come from any intake vacuum that you wanna run them from....
280zx!!! is offline   Reply With Quote
Old 10-25-2009, 10:27 AM   #9
Australian_Booster
Junior Member

Join Date: Sep 2009
Posts: 61
Australian_Booster is on a distinguished road
okay thanks mate. happy to see there are some people out there who will actually help instead of being a dumbass



Quote:
Originally Posted by 280zx!!! View Post
the lines to the bov and wastegate come from any intake vacuum that you wanna run them from....
Australian_Booster is offline   Reply With Quote
Old 10-25-2009, 10:28 AM   #10
Australian_Booster
Junior Member

Join Date: Sep 2009
Posts: 61
Australian_Booster is on a distinguished road
fail at life? what are you some faggot who judges peoples speech? what a joke


Quote:
Originally Posted by Jankenshank View Post
they run to the BOV and Wastegate.

also great fail at life....
Australian_Booster is offline   Reply With Quote
Old 10-25-2009, 11:19 AM   #11
Nicko
Member

Nicko's Avatar

Join Date: Feb 2008
Location: Tullahoma
Posts: 435
Nicko is on a distinguished road
Like posted, intake mani for your vacuum source. Be careful, because you do not want excessively long lines or them running over hot parts that can melt them.
Nicko is offline   Reply With Quote
Old 10-25-2009, 02:46 PM   #12
Australian_Booster
Junior Member

Join Date: Sep 2009
Posts: 61
Australian_Booster is on a distinguished road
right. yeah that almost happened with my blowoff valve line. okay i have one more question. when i got my wastegate, it came with two different kinds of bolts, and 2 bronze gold pieces that look like they hook to a hose. i have no idea how to install it all together.


Quote:
Originally Posted by Nicko View Post
Like posted, intake mani for your vacuum source. Be careful, because you do not want excessively long lines or them running over hot parts that can melt them.
Australian_Booster is offline   Reply With Quote
Old 10-25-2009, 02:58 PM   #13
Australian_Booster
Junior Member

Join Date: Sep 2009
Posts: 61
Australian_Booster is on a distinguished road
here is a picture of the wastegate and its hardware. can someone tell me where all the bolts and stuff hook up at?

Australian_Booster is offline   Reply With Quote
Old 10-25-2009, 03:45 PM   #14
Rajin
Skrim FML
Full-Time Post Whore

Rajin's Avatar

Join Date: Mar 2007
Location: Cookeville, TN
Posts: 5,392
Rajin is an unknown quantity at this point
Send a message via AIM to Rajin Send a message via Skype™ to Rajin
Oh boy. I know what type of parts those are....

Know exactly where they came from too.
__________________
PM Me For PC Builds
Also capable of doing network installs.
Most Everything I say is a Warhammer 40K reference.
Rajin is offline   Reply With Quote
Old 10-25-2009, 04:00 PM   #15
Australian_Booster
Junior Member

Join Date: Sep 2009
Posts: 61
Australian_Booster is on a distinguished road
okay cool.. i bet you do..



Quote:
Originally Posted by Rajin View Post
Oh boy. I know what type of parts those are....

Know exactly where they came from too.
Australian_Booster is offline   Reply With Quote
Old 10-25-2009, 04:02 PM   #16
Australian_Booster
Junior Member

Join Date: Sep 2009
Posts: 61
Australian_Booster is on a distinguished road
guys, if your gonna get on this thread and respond.. say something that is gonna pertain to the question i posted. dont leave stupid junk that nobody cares about
Australian_Booster is offline   Reply With Quote
Old 10-25-2009, 05:53 PM   #17
1126eclipse
dsm whore
Senior Member

1126eclipse's Avatar

Join Date: Mar 2007
Location: Murfreesboro
Posts: 1,925
1126eclipse is on a distinguished road
2 bolts screw into the flange which connects to your manifold. The others are for the wastegate to actaully open up which means you want to put those gold piece's inside the bolt and screw into the wastegate.
1126eclipse is offline   Reply With Quote
Old 10-25-2009, 08:20 PM   #18
T3AM SPOTLIT3
yes i'm RICE
Tennspeed Addict

T3AM SPOTLIT3's Avatar

Join Date: Apr 2008
Location: nashville
Posts: 3,689
T3AM SPOTLIT3 is on a distinguished road
Send a message via AIM to T3AM SPOTLIT3
You can hook it up to any nipple that is after the t/b on the mainfold,
Hope it help,I run mine to the fpr with a T nipple
__________________
T3AM SPOTLIT3 is offline   Reply With Quote
Old 10-26-2009, 12:40 AM   #19
Australian_Booster
Junior Member

Join Date: Sep 2009
Posts: 61
Australian_Booster is on a distinguished road
can you put up some pictures of how everything is hooked up?



Quote:
Originally Posted by T3AM SPOTLIT3 View Post
You can hook it up to any nipple that is after the t/b on the mainfold,
Hope it help,I run mine to the fpr with a T nipple
Australian_Booster is offline   Reply With Quote
Old 10-26-2009, 02:16 AM   #20
280zx!!!
Member

280zx!!!'s Avatar

Join Date: Jun 2008
Posts: 698
280zx!!! is on a distinguished road
alright here's a good rundown...go to a parts vendor(advanced auto or whatever you prefer) grab a ton of tiny hose clamps, and 2 or 3 vacuum line tee's...now find some vacuum lines while the car is running and pull them to ensure your getting a good amount of pressure from it(you'll hear it and can feel it) cut the line in half install the tee then plug your wastegate/bov/gauge to it repeat this step as many times as you have things to hook up....

now use hose clamps (if desired) if you dont want vacuum lines coming off your wastegate and pushing your turbo to 20lbs. i would...also another good thing to use for your gauge is solid plastic vacuum line...it doesnt flex as much as the rubber and gives you a more accurate reading...
